…ration Adds BasicLabelPinSelector.vue to edit a winding's name and its connections (pin name, terminal type and lead length) in the Wire Configuration panel. Connections are MAS metadata, so edits don't invalidate the wound geometry. The pin field is a dropdown when the bobbin declares pins, otherwise a free-text input; lead length is entered in mm and stored in metres, and the connection count is clamped to 2x numberParallels. Renaming a winding propagates to the construction references so name-matched derived views stay consistent.
Extends the Wire Configuration pin/connection editor (BasicLabelPinSelector) with a blind (internal winding-to-winding) connection: - add "Blind" to the connection Type dropdown - when a row's type is Blind, render the Name field as an <input list> + <datalist> combobox: free text to mint a node id, plus a dropdown of blind node ids already used on any winding (pick one to join this winding to it) - disable the Length input on blind rows (an internal joint has no lead length) Two windings sharing the same Blind pinName are joined. "Blind" is a local string value (not yet in the generated MAS.ts ConnectionType enum) and round-trips to MAS verbatim. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
Author
|
Correction to my note above — the engine does validate connection.type. On a design that loads cleanly, changing only two connections to {"type":"Blind"} makes masAutocomplete (run on every load via checkAndFixMas) throw Input JSON does not conform to schema!, and the coil then fails to wind. So any blind design currently fails to load. I've added Blind/blind to the connectionType enum across the stack — MAS + MKF/MAS schemas, MAS.hpp (from_json/to_json), and the MAS.ts / PyMKF / WebBackend copies (happy to PR the MKF/MAS change). The one piece I can't do is rebuilding libMKF.wasm — it lives in the private WebLibMKF (gpitel 404s on it). Could you grant access so I can rebuild it, or rebuild it with the enum value added? |
