Engram PoC

A proof-of-concept implementing hash-based O(1) memory lookup for transformer models, based on DeepSeek's "Engram: Conditional Memory via Scalable Lookup" paper.

Latest Updates

Blog Post: DeepSeek Papers Part 3 - Engram Revisited - Deep dive into what works, what doesn't, and practical guidelines for hash-based memory.

Key Findings

Query Type	Engram Accuracy	Baseline	Improvement
Acronym Expansion	75%	12%	+525%
Element Names	67%	0%	+∞
Random Synthetic	0%	0%	No benefit

Insight: Engram excels at structured lookups (ACRONYM:GPU → "Graphics Processing Unit") but doesn't help with arbitrary key-value mappings. This matches the DeepSeek paper's finding: "Delegating local dependencies to lookups frees up attention capacity for global context."

Conditional Engram Routing (New!)

Smart routing that activates Engram memory only when appropriate:

from src.memory import create_conditional_engram

model, tokenizer = create_conditional_engram(
    engram_weights_path="adapters-engram-exact/engram_weights.pt"
)
# Automatically routes lookups → Engram, general queries → bypass

Routing Behavior:

Input	Confidence	Route	Output
ACRONYM:GPU	1.0	ENGRAM	Graphics Processing Unit
CAPITAL:France	1.0	ENGRAM	Paris
What is the capital of France?	0.7	ENGRAM	Paris
Write a poem about cats	0.0	BYPASS	(base model response)
How do I sort a list?	0.0	BYPASS	(base model response)

Architecture

Hash-Based Memory Module

┌─────────────────────────────────────────────────────────────┐
│                    EnhancedEngramModule                      │
│  ┌─────────────┐    ┌─────────────┐    ┌─────────────┐     │
│  │ Multi-Head  │    │   Memory    │    │  Gated      │     │
│  │ Hashing     │ → │   Table     │ → │  Blending   │     │
│  │ (4 heads)   │    │ (500 slots) │    │  (learned)  │     │
│  └─────────────┘    └─────────────┘    └─────────────┘     │
│       ↑                                      ↓              │
│   input_ids                           hidden_states         │
└─────────────────────────────────────────────────────────────┘

Key Components:

• Multi-Head Hashing: 4 parallel hash functions for collision handling
• Memory Table: 500-slot embedding table (configurable)
• Gated Blending: Learned gate mixing memory with base activations
• Layer Injection: Wraps every transformer layer

Conditional Routing

┌─────────────────────────────────────────────────────────────┐
│                  ConditionalEngramWrapper                    │
│  ┌─────────────┐                                            │
│  │  Pattern    │  "ACRONYM:GPU" → 1.0                       │
│  │  Detector   │  "What is..." → 0.7                        │
│  │             │  "Write poem" → 0.0                        │
│  └─────────────┘                                            │
│        ↓                                                    │
│  ┌─────────────┐    ┌─────────────┐                        │
│  │  conf ≥ 0.5 │ → │   ENGRAM    │ → Memory-augmented      │
│  │  conf < 0.5 │ → │   BYPASS    │ → Base model only       │
│  └─────────────┘    └─────────────┘                        │
└─────────────────────────────────────────────────────────────┘

Quick Start

Prerequisites

• Apple Silicon Mac (M1/M2/M3/M4) or NVIDIA GPU
• Python 3.10+
• uv package manager

Setup

git clone https://github.com/softwarewrighter/engram-poc.git
cd engram-poc

# Create virtual environment
uv venv .venv-torch
source .venv-torch/bin/activate

# Install dependencies
uv pip install torch transformers
uv pip install -r requirements.txt

Run Conditional Demo

python -m src.memory.demo_conditional

This runs three demos:

1. Pattern Detection - Shows confidence scoring for different query types
2. Conditional Routing - Routes queries to Engram or bypasses based on patterns
3. Three-Way Comparison - Compares base, Engram, and conditional models

Train on Exact-Match Data

# Generate exact-match dataset
python -m src.data_gen.generate_exact_match

# Train Engram (requires GPU or MPS)
python scripts/train_engram.py \
    --train_file data/train_exact.jsonl \
    --valid_file data/valid_exact.jsonl \
    --output_dir adapters-engram-exact \
    --epochs 5

When to Use Engram

Good Use Cases

• Terminology expansion: ACRONYM:API → "Application Programming Interface"
• Factual lookup: CAPITAL:France → "Paris"
• Code patterns: HTTP:404 → "Not Found"
• Entity facts: ELEMENT:Fe → "Iron"

Poor Use Cases

• Arbitrary synthetic key-value pairs
• Creative/generative tasks
• Context-dependent answers
• Long-form reasoning

Success Criteria

Factor	Good for Engram	Bad for Engram
Pattern structure	Explicit prefix (CAPITAL:, PORT:)	Freeform text
Determinism	Single correct answer	Multiple valid responses
Repetition	Pattern seen 100+ times in training	Rare or unique
Locality	Answer derivable from key alone	Requires context

Project Structure

engram-poc/
├── src/memory/                    # Core Engram implementation
│   ├── engram_module.py          # EnhancedEngramModule (hash-based memory)
│   ├── model_wrapper.py          # EngramModelWrapper (layer injection)
│   ├── conditional_engram.py     # ConditionalEngramWrapper (smart routing)
│   └── demo_conditional.py       # Demo script
├── data/
│   ├── exact_5k/                 # 5K exact-match dataset
│   └── patterns/                 # Pattern YAML files
├── adapters-engram-exact/        # Trained Engram weights
├── results/                      # Evaluation results
├── scripts/                      # Training & evaluation scripts
└── docs/                         # Documentation

Documentation

Core Concepts

• Proposed Work - Detailed findings, experiments, and guidelines
• Comparison with weagan/Engram - Hash-based vs attention-based approaches
• ELI5 Explanation - What this repo does, pros/cons

Results

• MLX Results (Apple Silicon) - LoRA fine-tuning results
• CUDA Results (NVIDIA GPU) - Unsloth/NVIDIA results
• Exact-Match Evaluation - Hash-based memory results

Technical

• Architecture - System architecture
• Design - Technical design
• GPU Setup - NVIDIA GPU setup

External References

• Engram Paper (arXiv:2601.07372)
• DeepSeek Engram GitHub
• Hash Collision Study (arXiv:2601.16531) - Why collisions help

Platform Support

Apple Silicon (MPS)

source .venv-torch/bin/activate
python -m src.memory.demo_conditional

NVIDIA GPU (CUDA)

cd unsloth-nvidia/
source .venv/bin/activate
./scripts/run_all.sh

See unsloth-nvidia/README.md for detailed CUDA setup.

License

MIT License - see LICENSE for details.

---

Video Series

Watch the development journey on YouTube:

Full Playlist: Engram PoC Development

Latest: Part 4 - Hash-Based Memory Deep Dive

Earlier Episodes

Part	Topic	Link
Part 1	MLX on Apple Silicon	Watch
Part 2	Unsloth on NVIDIA GPU	Watch
Part 3	Short Explainer	Watch
Part 4	Hash-Based Memory	Watch

---

Contributing

See docs/process.md for development workflow and contribution guidelines.
