Grist - Enhanced Edition with AI & Vector Search

This enhanced version of Grist extends the powerful spreadsheet-database hybrid with semantic search capabilities and AI-powered embeddings, opening new possibilities for intelligent data management and retrieval.

🚀 What's New

Semantic Vector Search

Search your data by meaning, not just keywords. Find similar documents, detect duplicates, recommend content, and discover connections that traditional searches would miss.

Custom Vector Embeddings

Create tailored embeddings from specific fields to enable precise, context-aware searches that understand the semantic relationships in your data.

New Data Types

• Vector - Store and manipulate embedding vectors (1024 dimensions)
• Geometry - Handle spatial data with GeoJSON support

Spatial Functions

Built-in geospatial operations for location-based analytics:

• ST_DISTANCE() - Calculate distances between points
• ST_AREA() - Compute polygon areas
• ST_CONTAINS() - Test point containment
• ST_CENTROID() - Find geometric centers

🎯 Key Features

1. Automatic Semantic Indexing

Every table automatically generates semantic embeddings, making your data searchable by meaning:

# Find similar documents instantly
VECTOR_SEARCH(Documents, "quarterly financial report")

No configuration needed - it just works!

2. Custom Vector Embeddings

Create targeted embeddings from specific fields for specialized searches:

# Column A (Vector type) - Create custom embedding
CREATE_VECTOR($title, $summary, $tags)

# Column B (Reference List) - Search using custom embedding
VECTOR_SEARCH(Documents, $search_query, embedding_column="A")

Use cases:

• 📄 Document Management: Search by content, metadata, or both separately
• 🛍️ E-commerce: Match products by description, technical specs, or reviews
• 💬 Customer Support: Find relevant knowledge base articles from user questions
• 📊 Data Deduplication: Identify semantic duplicates with high threshold
• 🎯 Recommendation Systems: Suggest similar items based on attributes

3. Flexible Search Control

Fine-tune searches with threshold and limit parameters:

# Strict matching for high precision
VECTOR_SEARCH(Products, "laptop", threshold=0.85, limit=5)

# Broad matching for discovery
VECTOR_SEARCH(Articles, $user_question, threshold=0.6, limit=20)

Threshold guide:

• 0.6-0.7 - Broad semantic relevance
• 0.7-0.8 - Similar content
• 0.8-0.9 - Very similar
• 0.9+ - Near-identical (deduplication)

📖 Complete Function Reference

Vector Search Functions

VECTOR_SEARCH(table, query, threshold=0.75, limit=20, embedding_column=None)

Search records by semantic similarity.

Parameters:

• table - Table to search in
• query - Search text or column reference (e.g., "contracts" or $description)
• threshold - Minimum similarity (0.0 to 1.0, default: 0.75)
• limit - Maximum results (default: 20)
• embedding_column - Custom Vector column name (optional)

Returns: List of record IDs (Reference List compatible)

Examples:

# Basic search with auto-embedding
VECTOR_SEARCH(Documents, "annual report 2024")

# Search with custom embedding column
VECTOR_SEARCH(Files, "invoice", embedding_column="metadata_vector")

# Use column content as query
VECTOR_SEARCH(KnowledgeBase, $customer_question, threshold=0.7, limit=10)

# Find similar to current record
VECTOR_SEARCH(Products, $name + " " + $description, threshold=0.8, limit=5)

CREATE_VECTOR(*field_values)

Generate custom embedding from selected fields.

Parameters:

• *field_values - Any number of columns to combine (e.g., $col1, $col2, $col3)

Returns: 1024-dimension vector or None if generating

Examples:

# Embedding from title + description
CREATE_VECTOR($title, $description)

# Metadata-only embedding
CREATE_VECTOR($tags, $category, $author)

# Content-only embedding
CREATE_VECTOR($full_text_content)

# Multi-field combination
CREATE_VECTOR($title, $subtitle, $keywords, $summary, $notes)

VECTOR_SIMILARITY(vector1, vector2, method='cosine')

Calculate similarity between two vectors.

Parameters:

• vector1, vector2 - Vector columns or lists
• method - Similarity metric: 'cosine', 'euclidean', or 'manhattan'

Returns: Similarity score (0.0 to 1.0 for cosine)

Example:

VECTOR_SIMILARITY($embedding_A, $embedding_B, 'cosine')

Spatial Functions

ST_DISTANCE(point1, point2, unit='m')

Calculate distance between two points.

Parameters:

• point1, point2 - GeoJSON points {"type": "Point", "coordinates": [lon, lat]}
• unit - Distance unit: 'm', 'km', 'mi', 'ft'

Returns: Distance in specified unit

Example:

ST_DISTANCE($location, {"type": "Point", "coordinates": [2.3522, 48.8566]}, 'km')

ST_AREA(polygon, unit='m2')

Calculate polygon area.

Parameters:

• polygon - GeoJSON polygon
• unit - Area unit: 'm2', 'km2', 'ha', 'acre'

Example:

ST_AREA($property_boundary, 'ha')

ST_CONTAINS(polygon, point)

Test if polygon contains point.

Returns: True or False

Example:

ST_CONTAINS($delivery_zone, $customer_location)

ST_CENTROID(polygon)

Find geometric center of polygon.

Returns: GeoJSON Point

Example:

ST_CENTROID($region_boundary)

🎓 Practical Workflows

Workflow 1: Document Search System

Scenario: Build a knowledge base with semantic search

1. Create Documents table with columns:

   • title (Text)
   • content (Text)
   • tags (Text)
   • content_vector (Vector) = CREATE_VECTOR($content)
   • metadata_vector (Vector) = CREATE_VECTOR($title, $tags)

2. Create Search Interface table:

   • search_query (Text) - User input
   • content_results (Reference List) = VECTOR_SEARCH(Documents, $search_query, embedding_column="content_vector")
   • metadata_results (Reference List) = VECTOR_SEARCH(Documents, $search_query, embedding_column="metadata_vector")

3. Users can now:

   • Search by document content (technical details)
   • Search by metadata (categories, tags)
   • Compare different search strategies

Workflow 2: Product Recommendations

Scenario: Suggest similar products to customers

1. Products table:

   • name, description, specifications
   • product_vector (Vector) = CREATE_VECTOR($name, $description, $specifications)

2. Add recommendation column:

   • similar_products (Reference List) = VECTOR_SEARCH(Products, $description, threshold=0.75, limit=5, embedding_column="product_vector")

3. Result: Each product shows similar items automatically

Workflow 3: Support Ticket Routing

Scenario: Automatically find relevant solutions

1. Knowledge Base table:

   • problem, solution, category
   • kb_vector (Vector) = CREATE_VECTOR($problem, $category)

2. Tickets table:

   • customer_issue (Text)
   • suggested_articles (Reference List) = VECTOR_SEARCH(KnowledgeBase, $customer_issue, threshold=0.7, limit=3, embedding_column="kb_vector")

3. Result: Instant article suggestions for each ticket

Workflow 4: Deduplication

Scenario: Find and merge duplicate records

1. Add similarity column:

   • potential_duplicates (Reference List) = VECTOR_SEARCH(MyTable, $name + " " + $description, threshold=0.90, limit=5)

2. Review suggestions:

   • High threshold (0.90+) ensures only very similar records appear
   • Manual review for final merge decision

🔧 Technical Details

Embedding Technology

• Provider: Albert API (French Government AI)
• Model: albert-large for generation, embeddings-small for compact storage
• Dimensions: 1024 (configurable)
• Language Support: Multilingual, optimized for French

Performance

• Auto-embedding: Asynchronous generation with queue and retry
• Caching: MD5-based content hashing to avoid regeneration
• Search: Linear scan O(n) - suitable for tables up to ~100k records
• Similarity: Cosine distance (fast, normalized)

Data Persistence

• Embeddings stored as JSON arrays in Vector columns
• Auto-embeddings in special columns: grist_record_embedding, grist_embedding_hash
• Custom embeddings in user-defined Vector columns

Limitations

• Query must not be empty/None (returns [] if empty)
• Vector columns must have compatible dimensions
• Search is not indexed (brute-force comparison)

🛠️ Setup

Prerequisites

• Docker & Docker Compose
• Albert API key (for embeddings)

Environment Variables

# Albert API Configuration
ALBERT_API_URL=https://albert.api.etalab.gouv.fr/v1
ALBERT_API_TOKEN=your-api-token-here
ALBERT_MODEL=albert-large
ALBERT_MODEL_EMBEDDING=embeddings-small
EMBEDDING_DIMENSION=1024

# Grist Configuration
GRIST_SESSION_SECRET=your-session-secret
GRIST_FORCE_LOGIN=true

Running

docker-compose up -d

Access Grist at http://localhost:8484

📚 Resources

• Grist Documentation: https://support.getgrist.com/
• Vector Search Guide: See function docstrings in formula editor
• Albert API: https://albert.api.etalab.gouv.fr/docs
• GeoJSON Specification: https://geojson.org/

🤝 Contributing

This enhanced version builds upon the excellent foundation of Grist. Contributions are welcome:

1. Test new use cases and share feedback
2. Report issues with detailed reproduction steps
3. Suggest improvements to vector search algorithms
4. Add examples and tutorials

📄 License

Same as Grist core - Apache 2.0

---

Built with ❤️ on top of Grist

This enhanced edition adds semantic search capabilities while preserving all the powerful features that make Grist great.
