MCP ITSM

Unified IT Service Management over the Model Context Protocol — create, track, and resolve tickets across ServiceNow, Jira, Zendesk, Ivanti Neurons, and Cherwell from any MCP-compatible LLM client.

MCP Spec SDK Node License Smithery Glama

Table of Contents

Overview

MCP ITSM exposes a standardised set of MCP tools, resources, and prompts so that any LLM client (Claude, Cursor, custom agents) can manage IT tickets without knowing the underlying ITSM system's API.

What it is:

Layer What's here
index.js MCP server — 7 tools, 4 resources, 3 prompts over stdio
backend/ Express REST API that bridges HTTP clients to the MCP server via the official SDK Client
frontend/ React 18 web app — Ticket Manager UI + live Monitoring Dashboard

Why it matters:
Instead of writing separate integrations for ServiceNow, Jira, Zendesk, Ivanti, and Cherwell, an LLM calls create_ticket once and the correct system receives it. Every tool carries safety annotations (readOnlyHint, destructiveHint) so the model knows what it can call without risk.

Architecture

graph TB
    subgraph "MCP Clients"
        Claude["Claude / Cursor / Agent"]
        Inspector["MCP Inspector"]
        UI["React Frontend :3000"]
    end

    subgraph "Transport"
        Stdio["StdioServerTransport\n(Smithery / Inspector)"]
        Bridge["Express API :5000\nSDK Client + StdioClientTransport"]
    end

    subgraph "MCP Server  —  index.js  v3.0.0"
        McpSrv["McpServer\nspec 2025-11-25"]
        Tools["7 Tools\nZod · annotated"]
        Resources["4 Resources\nKB articles · Tickets"]
        Prompts["3 Prompts\nIncident · Status · KB-assist"]
        Store["In-Memory Store\nTickets & KB articles"]
    end

    subgraph "Backend Services"
        Auth["JWT Auth"]
        Metrics["Metrics Store"]
        Mongo[("MongoDB")]
    end

    Claude -->|stdio| Stdio
    Inspector -->|stdio| Stdio
    UI -->|HTTP + JWT| Bridge

    Stdio --> McpSrv
    Bridge -->|"MCP SDK Client\n(proper handshake)"| McpSrv

    McpSrv --> Tools
    McpSrv --> Resources
    McpSrv --> Prompts
    Tools <--> Store
    Resources --> Store

    Bridge --> Auth
    Bridge --> Metrics
    Auth --> Mongo
Loading

Request flow — browser tool call:

sequenceDiagram
    participant U as User
    participant UI as React UI :3000
    participant API as Express API :5000
    participant C as MCP SDK Client
    participant MCP as McpServer index.js

    U->>UI: Submit form
    UI->>API: POST /api/mcp/tools/call (JWT)
    API->>C: client.callTool(name, args)
    Note over C: StdioClientTransport
    C->>MCP: tools/call (MCP protocol)
    Note over MCP: Zod validates input
    MCP->>MCP: tool handler + in-memory store
    MCP-->>C: CallToolResult
    C-->>API: result
    API->>API: recordCall() → metrics
    API-->>UI: { success, data, _meta }
    UI->>U: Show result
Loading

Quick Start

Prerequisites

  • Node.js ≥ 18
  • MongoDB (local or Atlas — required by the backend)
  • Optional: Smithery CLI for cloud deployment

1 — Install dependencies

# Root (MCP server)
npm install

# Backend API
cd backend && npm install && cd ..

# Frontend
cd frontend && npm install && cd ..

2 — Configure environment

cp .env.example .env          # root — API key for Smithery / MCP auth
cp backend/.env.example backend/.env   # backend — Mongo URI, JWT secret, ITSM creds

Minimum required for local dev (edit backend/.env):

MONGODB_URI=mongodb://localhost:27017/mcp-itsm
JWT_SECRET=change-me-in-production

3 — Start all services

Open three terminals:

# Terminal 1 — MCP server (stdio)
npm start

# Terminal 2 — Backend API
cd backend && npm start        # http://localhost:5000

# Terminal 3 — Frontend
cd frontend && npm start       # http://localhost:3000
flowchart LR
    T1["Terminal 1\nnpm start\nMCP server on stdio"]
    T2["Terminal 2\ncd backend\nnpm start  :5000"]
    T3["Terminal 3\ncd frontend\nnpm start  :3000"]
    UI["localhost:3000\nTicket Manager\nMonitor Dashboard"]

    T1 -->|"SDK Client\nStdioClientTransport"| T2
    T2 -->|"HTTP + JWT"| T3
    T3 --> UI
Loading

Access points

URL What
http://localhost:3000 React web app
http://localhost:3000/mcp-tickets MCP Ticket Manager
http://localhost:3000/mcp-monitor Live Monitoring Dashboard
http://localhost:5000/health Backend health check
http://localhost:5000/api/mcp/health MCP server connectivity
http://localhost:5000/api/mcp/metrics Tool-call metrics (auth required)

Project Structure

mcp-itsm/
├── index.js                  # MCP server (McpServer, Zod, stdio)
├── tools.json                # Static tool catalogue for Smithery browser
├── smithery.yaml             # Smithery deployment config
├── package.json              # Root deps: @modelcontextprotocol/sdk, zod
├── .env.example              # Root env template
│
├── backend/
│   ├── package.json          # Express, Mongoose, JWT, MCP SDK Client
│   ├── .env.example          # Backend env template
│   └── src/
│       ├── index.js          # Express app bootstrap
│       ├── config/config.js  # Env-driven configuration
│       ├── routes/
│       │   ├── mcp.routes.js      # MCP bridge + metrics endpoints
│       │   ├── auth.routes.js
│       │   ├── context.routes.js
│       │   ├── integration.routes.js
│       │   └── user.routes.js
│       ├── middleware/
│       │   ├── auth.middleware.js
│       │   └── validation.middleware.js
│       ├── models/
│       ├── validators/
│       └── utils/logger.js
│
├── frontend/
│   ├── package.json          # React 18, Bootstrap, react-router-dom
│   └── src/
│       ├── App.js
│       ├── pages/
│       │   ├── MCPTicketManager.js     # Ticket CRUD UI
│       │   ├── MCPMonitorDashboard.js  # Live monitoring (polls every 10s)
│       │   ├── Dashboard.js
│       │   ├── LLMChatClient.js
│       │   └── ...
│       ├── services/
│       │   ├── mcpService.js   # HTTP client for MCP tool calls
│       │   └── api.js          # Axios instance with JWT interceptor
│       └── components/
│           ├── Header.js
│           └── ...
│
└── docs/
    ├── api-documentation.md
    ├── mcp_relationship.md
    └── llm_enabled_tickets.md

MCP Tools

All 7 tools are registered via McpServer.tool() with Zod input schemas and safety annotations. LLM clients use the annotations to decide whether to call a tool without user confirmation.

Tool Title Read-only Idempotent Required params
create_ticket Create Ticket — — title, description
get_ticket Get Ticket ✓ ✓ ticket_id
update_ticket Update Ticket — — ticket_id
list_tickets List Tickets ✓ ✓ —
assign_ticket Assign Ticket — ✓ ticket_id, user_id
add_comment Add Comment — — ticket_id, comment
search_knowledge_base Search KB ✓ ✓ query

Supported systems (via the optional system parameter): servicenow · jira · zendesk · ivanti_neurons · cherwell (default: jira)

graph LR
    subgraph RO["Read-only  —  safe to call freely"]
        GT["get_ticket\nreadOnly · idempotent"]
        LT["list_tickets\nreadOnly · idempotent"]
        SK["search_knowledge_base\nreadOnly · idempotent"]
    end
    subgraph WR["Write  —  require user intent"]
        CT["create_ticket\nwrite"]
        UT["update_ticket\nwrite"]
        AT["assign_ticket\nwrite · idempotent"]
        AC["add_comment\nwrite"]
    end
    style RO fill:#f0fdf4,stroke:#86efac
    style WR fill:#fff1f2,stroke:#fecdd3
Loading

Example — create a ticket

// Tool call
{
  "name": "create_ticket",
  "arguments": {
    "title": "VPN not connecting after Windows update",
    "description": "Since the KB5034441 update, VPN client fails to authenticate on first attempt.",
    "priority": "high",
    "system": "jira"
  }
}

// Response
{
  "success": true,
  "ticket": {
    "id": "JIRA-1000",
    "title": "VPN not connecting after Windows update",
    "system": "jira",
    "status": "open",
    "priority": "high",
    "url": "https://example.com/jira/tickets/JIRA-1000"
  }
}

MCP Resources

Resources expose live data that LLM clients can read without a tool call.

URI Name Description
kb://articles kb-articles All knowledge base articles (JSON)
kb://articles/{id} kb-article Single KB article by ID (e.g. KB-001)
itsm://tickets/open open-tickets All currently open tickets (live)
itsm://tickets/{ticketId} ticket Single ticket by ID (e.g. JIRA-1000)
graph LR
    McpSrv["McpServer"]
    McpSrv -->|"static\nkb://articles"| KBAll["kb-articles\nAll KB articles as JSON"]
    McpSrv -->|"template\nkb://articles/{id}"| KBOne["kb-article\nSingle article by ID"]
    McpSrv -->|"static\nitsm://tickets/open"| TOpen["open-tickets\nLive filtered view"]
    McpSrv -->|"template\nitsm://tickets/{id}"| TOne["ticket\nSingle ticket by ID"]
    style McpSrv fill:#f0fdf4,stroke:#86efac
Loading

MCP Prompts

Prompts are guided message templates that clients present to users before a tool call sequence.

Name Description Arguments
create-incident-ticket P1/P2 incident ticket template title (req), system, affected_service
ticket-status-report Structured queue summary filter_status
kb-search-assist Search KB before creating a ticket issue_description (req)
sequenceDiagram
    participant U as User
    participant C as MCP Client
    participant MCP as McpServer

    U->>C: "My printer won't install"
    C->>MCP: prompts/get  kb-search-assist
    MCP-->>C: message template
    C->>MCP: tools/call  search_knowledge_base
    MCP-->>C: KB-005 Printer setup guide
    C->>U: Show article — no ticket needed
    Note over C,U: Only escalates to create_ticket if no article resolves it
Loading

Configuration

Root .env (MCP server + Smithery)

# API key used when running via Smithery (injected as API_KEY env var)
API_KEY=your-smithery-api-key

Backend backend/.env

# Server
PORT=5000
NODE_ENV=development

# Database
MONGODB_URI=mongodb://localhost:27017/mcp-itsm

# Auth
JWT_SECRET=change-me-to-a-long-random-string
JWT_EXPIRES_IN=1d

# ITSM integrations (all optional — only needed for live system calls)
SERVICENOW_BASE_URL=https://your-instance.service-now.com
SERVICENOW_USERNAME=admin
SERVICENOW_PASSWORD=

JIRA_BASE_URL=https://your-org.atlassian.net
JIRA_EMAIL=you@example.com
JIRA_API_TOKEN=

ZENDESK_BASE_URL=https://your-org.zendesk.com
ZENDESK_USERNAME=you@example.com
ZENDESK_TOKEN=

IVANTI_BASE_URL=https://your-instance.ivanti.com
IVANTI_CLIENT_ID=
IVANTI_CLIENT_SECRET=

CHERWELL_BASE_URL=https://your-instance.cherwell.com
CHERWELL_CLIENT_ID=
CHERWELL_USERNAME=
CHERWELL_PASSWORD=

# Logging
LOG_LEVEL=info

Monitoring Dashboard

The frontend includes a live monitoring dashboard at /mcp-monitor that polls the backend every 10 seconds.

What it shows:

  • Server connected / disconnected status with uptime
  • Total calls, success rate, failed call count
  • Per-tool call statistics with average latency badges
  • Available tools with annotation labels (read-only, write, idempotent)
  • Registered resources and prompts
  • Live activity log of the last 20 tool calls

The data is sourced from the in-memory metrics store in backend/src/routes/mcp.routes.js and reset on backend restart.

flowchart TD
    DB["React Dashboard\n/mcp-monitor\npoll every 10 s"]
    DB -->|"GET /api/mcp/health"| H["connected · uptimeSeconds"]
    DB -->|"GET /api/mcp/metrics"| M["totalCalls · successRate\ntoolStats · recentCalls"]
    DB -->|"GET /api/mcp/tools/list"| T["tool names + annotations"]
    DB -->|"GET /api/mcp/resources/list"| R["resource URIs"]
    DB -->|"GET /api/mcp/prompts/list"| P["prompt names"]
Loading

API Reference

All /api/mcp/* endpoints require a valid JWT in the Authorization: Bearer <token> header.

Method Path Description
GET /api/mcp/health MCP server connectivity + backend uptime
GET /api/mcp/metrics Tool-call metrics (counts, latency, recent calls)
GET /api/mcp/tools/list List all registered tools with schemas + annotations
POST /api/mcp/tools/call Call a tool — body: { name, arguments }
GET /api/mcp/resources/list List registered MCP resources
GET /api/mcp/prompts/list List registered MCP prompts

Tool call example (curl)

# Authenticate first
TOKEN=$(curl -s -X POST http://localhost:5000/api/auth/login \
  -H "Content-Type: application/json" \
  -d '{"email":"admin@example.com","password":"password"}' | jq -r '.token')

# Call a tool
curl -X POST http://localhost:5000/api/mcp/tools/call \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "search_knowledge_base",
    "arguments": { "query": "vpn", "limit": 3 }
  }'

Smithery Deployment

The server is published at @madosh/mcp-itsm on Smithery.

flowchart LR
    Dev["Developer\nnpm publish via\nsmithery publish"]
    Smithery["Smithery Cloud\nDocker container\nenv API_KEY injected"]
    MCPSrv["McpServer v3.0.0\nnpm start → stdio"]
    Client["Claude / Cursor\nany MCP client"]

    Dev -->|"smithery.yaml\ntools.json"| Smithery
    Smithery -->|"spawn"| MCPSrv
    Client -->|"MCP protocol\nstdio"| Smithery
    Smithery <-->|"proxy"| MCPSrv
Loading

Install via Smithery CLI

npx -y @smithery/cli install @madosh/mcp-itsm --client claude

Manual Smithery deploy

npm install -g @smithery/cli
smithery login
smithery publish

The smithery.yaml configuration:

startCommand:
  type: stdio
  configSchema:
    type: object
    required: [apiKey]
    properties:
      apiKey:
        type: string
  commandFunction: |-
    (config) => ({ command: 'npm', args: ['start'], env: { API_KEY: config.apiKey } })
tools:
  path: ./tools.json

Use with Claude Desktop

Add to claude_desktop_config.json:

{
  "mcpServers": {
    "mcp-itsm": {
      "command": "node",
      "args": ["/absolute/path/to/mcp-itsm/index.js"],
      "env": { "API_KEY": "your-key" }
    }
  }
}

Debug with MCP Inspector

npm run debug-mcp
# Opens MCP Inspector at http://localhost:5173

Development

Available scripts

# Root
npm start              # Start MCP server on stdio
npm run debug-mcp      # Start with MCP Inspector attached

# Backend
cd backend
npm start              # Production
npm run dev            # Development (nodemon hot-reload)
npm test               # Jest test suite

# Frontend
cd frontend
npm start              # Dev server on :3000
npm run build          # Production build

Tech stack

Layer Technologies
MCP Server Node.js 18+, @modelcontextprotocol/sdk 1.28.0, Zod 3.23
Backend Express 4, Mongoose 7, JWT, Helmet, Winston
Frontend React 18, React Router 6, Bootstrap 5
MCP Spec 2025-11-25
Deployment Smithery (stdio), Docker

Running with Docker

docker build -t mcp-itsm .
docker run -e API_KEY=your-key mcp-itsm

Contributing

Contributions are welcome. Please:

  1. Fork the repository
  2. Create a feature branch (git checkout -b feat/my-feature)
  3. Commit your changes (git commit -m 'feat: add my feature')
  4. Push to the branch (git push origin feat/my-feature)
  5. Open a Pull Request

Roadmap

  • OAuth 2.1 / OIDC authorization for external clients
  • Elicitation — server-initiated mid-call user prompts
  • Experimental Tasks — durable async ticket workflows
  • Live ITSM system adapters (ServiceNow, Jira, Zendesk)
  • outputSchema / structuredContent on all tools
graph LR
    subgraph Done["Shipped in v3.0.0"]
        D1["SDK 1.28.0 + Zod"]
        D2["McpServer API"]
        D3["Tool annotations"]
        D4["Resources + Prompts"]
        D5["SDK Client transport"]
        D6["Metrics + Dashboard"]
    end
    subgraph Next["Next"]
        N1["OAuth 2.1 / OIDC"]
        N2["Elicitation"]
        N3["Tasks API"]
        N4["Live ITSM adapters"]
    end
    style Done fill:#f0fdf4,stroke:#86efac
    style Next fill:#eff6ff,stroke:#bfdbfe
Loading

License

MIT — see LICENSE for details.

Resources

About

No description, website, or topics provided.

Resources

Readme

License

MIT license
Activity

Stars

3 stars

Watchers

1 watching

Forks

0 forks
Report repository

Releases

No releases published

Packages





Contributors

Languages
