Nest Legacy Integration for Home Assistant

This is a custom component for Home Assistant to integrate a wide range of Nest devices using an unofficial web API (combining REST streaming and Protobuf). It serves as an alternative to the official Nest integration, providing support for devices not available through Google's official Smart Device Management (SDM) API, such as the Nest Protect, Nest x Yale Lock, and Nest Heat Link.

This integration provides real-time updates for most sensors and controls by maintaining persistent connections to the Nest API.

Why use Nest Legacy?

The official Home Assistant Nest integration uses Google's Smart Device Management (SDM) API, which has a limited set of supported devices and requires a one-time $5 fee. This Nest Legacy integration uses the same unofficial APIs that the Nest mobile and web apps use, offering several key advantages.

Comparison with the Official Nest Integration

Feature	Nest Legacy (This Integration)	Official Nest Integration (SDM API)
API Used	Unofficial Nest Web API (REST & Protobuf)	Official Google SDM API
Cost	Free	$5 USD one-time fee required by Google
Authentication	Access Token (Nest Account) or Cookies (Google Account)	OAuth2 with Google Cloud Project
Supported Devices	Wider range, including Nest Protect, Nest Temp Sensors, Nest x Yale Locks, and Nest Heat Link.	Limited to newer Thermostats, Cameras, and Doorbells.
Data Updates	Push-based (Subscriber/Observer)	Push-based (Pub/Sub)
Stability	Relies on an unofficial API that could change or break without notice.	Officially supported by Google, more stable long-term.

In short, use this integration if you want to:

• Integrate Nest Protects, Temperature Sensors, Locks, or Heat Links.
• Avoid the $5 Google API fee.
• Access features not exposed by the official API (e.g., Protect component health tests, Heat Link boost, controlling Thermostat via specific Temp Sensors).

Supported Devices

This integration supports a wide variety of Nest devices:

• Nest Thermostats (1st, 2nd, 3rd gen, Thermostat E, 2020 mirror edition)
• Nest Protect (1st and 2nd gen, both wired and battery)
• Nest Temperature Sensors (Kryptonite)
• Nest Cameras (Cam Indoor, IQ Indoor, Outdoor, IQ Outdoor)
• Nest Doorbells (Wired 1st gen)
• Nest x Yale Locks
• Nest Heat Link (for UK/EU hot water control)

Features & Entities

This integration creates a rich set of entities for your Nest devices based on their capabilities.

Nest Thermostat

• Climate: Full control over temperature, HVAC modes (Heat, Cool, Heat/Cool, Off), and Presets (None, Eco). Supports Target Humidity if a humidifier/dehumidifier is present.
• Fan: Independent control of the fan (On/Off, Speed/Percentage).
• Sensors: Current Temperature, Target Temperature, Humidity, Target Humidity, Backplate Temperature, Filter Runtime.
• Binary Sensors: Occupancy, Leaf status (Eco indicator), Filter Replacement Needed.
• Switches: Temperature Lock, Dehumidifier State.

Nest Temperature Sensor

• Sensors: Current Temperature, Battery Level.
• Switch: Control Thermostat (Active Sensor). Turning this switch on forces the associated thermostat to use this sensor's reading for climate control.

Nest Protect

• Binary Sensors: Smoke Status, CO Status, Heat Status.
• Diagnostic Binary Sensors: Battery Health, Line Power (wired only), Occupancy (wired only), Removed from Base status.
• Component Tests: Sensors indicating pass/fail for Speaker, Smoke, CO, WiFi, LED, PIR, Buzzer, and Humidity sensors.
• Sensors: Battery Level (%), Replace By Date, Last Manual Test time, Last Audio Self-Test time.
• Switches: Nightly Promise (Green LED), Heads-Up Alerts, Steam Check, Night Light enable.
• Select: Night Light Brightness (Low, Medium, High).

Nest Cameras & Doorbells

• Camera: Live streaming entity.
• Switches: Streaming Enabled, Audio Recording, Indoor Chime (Doorbell), Visitor Announcements (Doorbell), Night Vision (IR), Status LED, Video Rotation.
• Events: event entities that trigger on Motion, Person, Sound, Face Detection, and Doorbell Chime.
• Media Browser: Browse, play, and see thumbnails for historical camera events directly in the Home Assistant Media Browser.

Nest x Yale Lock

• Lock: Lock and unlock control.
• Sensors: Battery Level, Last Actor (who locked/unlocked: Keypad, Manual, Remote, Voice, etc.).
• Binary Sensor: Tamper detection.
• Switch: Auto-Relock enable/disable.
• Number: Configure the Auto-Relock duration (seconds).

Nest Heat Link (Europe)

• Water Heater: Control hot water heating.

• Operation Modes: Supports off, schedule, and several boost durations (boost, boost_30m, boost_1h, boost_2h).

• Boost Mode: Activates hot water for a specified duration (default 30 minutes for boost). The reported operation mode will dynamically update to reflect the remaining boost time (e.g., switching from Boost (2h) to Boost (1h) as time passes). Once the boost timer expires, the device automatically reverts to the previous mode (e.g., schedule).

• Features: Set target temperature, toggle Away mode.

• Automation: You can trigger a boost via automation using the water_heater.set_operation_mode action:

  automation:
    triggers:
      - trigger: time
        at: "07:15:00"
    actions:
      - action: water_heater.set_operation_mode
        target:
          entity_id: water_heater.nest_heat_link
        data:
          operation_mode: boost_1h # Boost for 1 hour

Structure (Home)

• Select: Set the structure mode (Home, Away, Sleep, Vacation).

Custom Actions

This integration provides several custom actions for advanced functionality, especially for managing guest access on Nest x Yale Locks.

nest_legacy.list_guests

Lists all guests configured on your Nest structures. This action returns a list of guests, which can be viewed in the Home Assistant trace or used in scripts with response data.

• Data:
  • config_entry_id (Optional): The config entry of the Nest Legacy integration. Required if you have multiple Nest Legacy entries.

nest_legacy.get_user_schedule

Gets the access schedule for a specific user on a lock. This action returns the schedule details.

• Data:
  • device_id (Required): The lock device to target.
  • user_id (Required): The user or guest resource ID (e.g., GUEST_1234).

nest_legacy.set_user_schedule

Sets the access schedule for a user on a lock.

• Data:
  • device_id (Required): The lock device to target.
  • user_id (Required): The user or guest resource ID (e.g., GUEST_1234).
  • days_of_week (Optional): The days of the week when access is allowed (e.g., monday, tuesday).
  • start_time (Optional): The time of day when access starts (e.g., 14:00:00).
  • duration (Optional): The length of the daily access window (e.g., 04:00:00).
  • start_timebox (Optional): The date and time when access begins.
  • end_timebox (Optional): The date and time when access expires.

nest_legacy.delete_user_schedule

Deletes the access schedule for a user on a device.

• Data:
  • device_id (Required): The lock device to target.
  • user_id (Required): The user or guest resource ID (e.g., GUEST_1234).

Installation

HACS

This integration is included in the default HACS repository.

1. Open HACS in Home Assistant.
2. Search for "Nest Legacy" in the Integrations section and click download.
3. Restart Home Assistant.
4. Go to Settings > Devices & Services > Add Integration > Search for "Nest Legacy".

Configuration

After installation, the integration can be configured via the Home Assistant UI.

You will be asked to select your account type. Follow the instructions below based on your account.

Option A: Google Account

For accounts migrated to Google, or created after August 2019. You will need to retrieve an issue_token and cookies from your browser.

⚠️ CRITICAL BROWSER WARNING: Do NOT use Google Chrome or Microsoft Edge to get these cookies. Chromium-based browsers use aggressive, hardware-bound security sessions with Google. If you use Chrome, your integration will authenticate successfully but will fail after a few hours or immediately upon restarting Home Assistant. Spoofing the User-Agent in Chrome will not bypass this. You MUST use Safari or Firefox to capture a long-lived cookie.

Recommended Method: Nest Token Extractor (Easiest)

We recommend using the Nest Token Extractor browser extension to automatically capture and format these credentials for you in seconds.

1. Install the extension for Firefox or Safari (do not use Chrome).
2. Open the extension, choose your environment, and click Open Nest & Start Extraction.
3. Sign in to your account. Copy the extracted Issue Token and Cookies straight into Home Assistant!
4. Firefox Users: If the Cookies field remains blank, click the Shield icon in your Firefox address bar on home.nest.com and toggle off Enhanced Tracking Protection, then retry.

Manual Method

(Instructions adapted from the homebridge-nest project).

1. Open a Safari or Firefox browser tab.
   • Do NOT use Private/Incognito mode in Firefox, as it enforces strict cookie isolation that will result in a "No active session found" error, even if tracking protection is disabled.
   • Firefox Users: You MUST click on the Shield icon in the Firefox address bar on home.nest.com and uncheck/toggle off Enhanced Tracking Protection (both on home.nest.com and accounts.google.com if prompted). If ETP is enabled, Firefox blocks or isolates Google's cookies inside the nested iframe, resulting in Invalid authentication in Home Assistant.
2. Open Developer Tools (usually right-click -> Inspect, or in Safari: Develop -> Show Web Inspector).
3. Click on the Network tab. Make sure Preserve Log (or "Persist Logs") is checked.
4. In the 'Filter' box, enter issueToken.
5. Go to home.nest.com, and click Sign in with Google. Log into your account.
6. One network call (beginning with iframerpc) will appear in the Dev Tools window. Click on it.
7. In the Headers tab, under General (or "Headers" in Safari), copy the entire Request URL. This is your Issue token.
8. Clear the filter box and now enter oauth2/iframe.
9. Several network calls will appear. Click on the last iframe call.
10. In the Headers tab, under Request Headers, find the cookie entry. Copy the entire cookie string (it will be very long). This is your Cookies.
11. Paste these values into the Home Assistant configuration form.
12. Do not log out of home.nest.com, as this will immediately invalidate your credentials. Just close the browser tab.

Option B: Legacy Nest Account

For older, non-migrated Nest accounts. You will need to obtain an access_token.

1. Go to https://home.nest.com in your browser and log in.
2. Once logged in, open a new tab and go to https://home.nest.com/session.
3. You will see a long string of text. Find "access_token": "..." near the beginning.
4. Copy the value inside the quotes (it's a long sequence of letters, numbers and punctuation beginning with b). This is your Access token.
5. Paste this value into the Home Assistant configuration form.
6. Do not log out of home.nest.com, as this will invalidate your credentials. Just close the browser tab.

Field Test Environment

If you are part of the Google Field Test program, check the "Use Field Test environment" box during setup.

Configuration Options

Once set up, you can click "Configure" on the integration entry to tweak settings:

• Camera Event Poll Interval: How often to check for new camera events (default: 5 seconds).
• Protobuf Options: Enable/Disable the use of the newer Protobuf API for specific device types (Locks, Thermostats, Protects, Structure, Cameras).

Troubleshooting

• Authentication Errors: If you receive authentication errors, your cookies or tokens may have expired. You will need to re-fetch them using the steps above and use the "Reconfigure" option in the integration.
• "No active session found" / Invalid authentication on setup: If your debug logs show BadCredentialsException('No active session found.'), the cookies you provided did not contain a valid Google login session. This is almost always caused by browser privacy settings (like Firefox's Enhanced Tracking Protection) or using a Private/Incognito window which isolates cross-site cookies. Try again in a normal window (you can create a fresh browser profile if you want to avoid logging out of your primary account) or use the recommended Nest Token Extractor extension.
• Missing Devices: Ensure your devices are visible in the Nest app. Some newer Google Nest devices (like the 2021+ battery cameras) are exclusively on the Google Home app and may not appear here, or may have limited functionality via the legacy API.

Credits

This integration would not be possible without the extensive research and work done by these projects:

• https://github.com/chrisjshull/homebridge-nest
• https://github.com/n0rt0nthec4t/homebridge-nest-accfactory
• https://github.com/iMicknl/ha-nest-protect

Screenshots

Configuration Screenshots

Nest Protect Screenshot

Nest Thermostat Screenshot

Nest Camera Screenshot

Nest Doorbell Screenshot

Nest Lock Screenshot

Home Screenshot

Media Browser Screenshot

Disclaimer

This is a personal hobby project and is not affiliated with Google or Nest. It uses an unofficial API that could be changed or discontinued by Google at any time, which may cause this integration to stop working. It is provided "as-is," with no warranty whatsoever. Use at your own risk.
