drivers/qma6100p: add QST QMA6100P 3-axis accelerometer driver by leduclean · Pull Request #22352 · RIOT-OS/RIOT

leduclean · 2026-06-06T16:15:34Z

Add a driver for the QST QMA6100P 3-axis accelerometer over I2C.

This driver was needed to support the Seeed Studio SenseCAP T1000-E tracker,
which embeds a QMA6100P as its motion sensor.

Features:

Configurable full-scale range, output data rate and power mode
Acceleration readout on all three axes
Data-ready interrupt support
SAUL integration
Kconfig configuration

Includes a test application under tests/drivers/qma6100p covering basic
readout and the data-ready interrupt.

Testing procedure

Wire a QMA6100P to a board exposing an I2C bus (e.g. the Seeed Studio SenseCAP
T1000-E), then build and flash the test application (adjust BOARD and the I2C
parameters as needed):

BOARD=<your-board> make -C tests/drivers/qma6100p flash term

The test:

Initializes the device over I2C.
Runs a data-ready interrupt rate sweep at 12.5 / 25 / 100 Hz, measuring the
ISR frequency and asserting it matches the configured ODR.
Streams samples: the data-ready ISR signals a reader thread that reads each
sample over I2C.

Expected output:

=== QMA6100P accelerometer driver test ===
[init] I2C_DEV(0) addr 0x12 ... OK

--- data-ready interrupt rate sweep ---
[ODR 1/3] set rate -> 12 Hz ... OK
  try 1/3: measured 12 Hz (expect ~12) -> PASS
[ODR 1/3] PASS (~12 Hz)
[ODR 2/3] set rate -> 25 Hz ... OK
  try 1/3: measured 25 Hz (expect ~25) -> PASS
[ODR 2/3] PASS (~25 Hz)
[ODR 3/3] set rate -> 100 Hz ... OK
  try 1/3: measured 100 Hz (expect ~100) -> PASS
[ODR 3/3] PASS (~100 Hz)

=== ALL TESTS PASSED ===

--- interrupt-driven streaming ---
[data] x=... y=... z=... ug
...

Issues/PRs references

#22267

Useful link

QMA6100P spec

Declaration of AI Tools / LLMs usage

Claude Code for code review and guidance, with user authorship of the implementation

Co-authored-by: Baptiste Le Duc baptiste.leduc@etik.com
Signed-off-by: Léandre Le Duc leandre.leduc38@gmail.com

Add a driver for the QST QMA6100P 3-axis accelerometer over I2C. Features: - Configurable full-scale range, output data rate and power mode - Acceleration readout on all three axes - Data-ready interrupt support - SAUL integration - Kconfig configuration Includes a test application under tests/drivers/qma6100p covering basic readout and the data-ready interrupt. Co-authored-by: Léandre Le Duc <leandre.leduc38@gmail.com> Signed-off-by: Baptiste Le Duc <baptiste.leduc@etik.com>

github-actions · 2026-06-06T16:15:43Z

Hey @leduclean, thank you for your first contribution! We really appreciate it! If you haven't already, please take a look at our contributing guidelines before the review process starts. Also, due to how the GitHub review system works, please avoid force-pushing or squashing your commits unless asked to by a maintainer (or unless your commit is still in "draft commit" stage). Your pull request will be reviewed as soon as possible.

riot-ci · 2026-06-06T21:32:03Z

Murdock results

❌ FAILED

f13dc60 drivers/qma6100p: add QST QMA6100P 3-axis accelerometer driver

Success	Failures	Total	Runtime
3173	0	10422	04m:08s

Artifacts

AnnsAnns · 2026-06-07T15:08:54Z

First Sanji and now Foxy, seems like there is a theme here 😛

Thank you for your PR, it seems like there are still some issues you need to fix to get through our CI, see here: https://ci.riot-os.org/details/b17c1a96704744cbb4adb7763282d497

I'd presume that @baptleduc can vouch for the functionality of this?

baptleduc · 2026-06-07T15:12:13Z

First Sanji and now Foxy, seems like there is a theme here 😛

Thank you for your PR, it seems like there are still some issues you need to fix to get through our CI, see here: https://ci.riot-os.org/details/b17c1a96704744cbb4adb7763282d497

I'd presume that @baptleduc can vouch for the functionality of this?

Ahah brothers fans of one piece 😄

Yes I will fix it but @leduclean already took a look and he struggled to find what was the real issue

baptleduc · 2026-06-07T15:26:13Z

It is weird because the murdock error indicates it is because of map_regs variable that could be used uninitialized in qma6100p_set_data_ready_interrupt() while there are no branches where it could be the case.

Could you please help us to understand this ?

Thanks !

AnnsAnns · 2026-06-07T17:57:57Z

Hmmm does this also happen when you run the test locally or only on murdock?

crasbe · 2026-06-07T18:33:03Z

The compiler complains about the use of map_reg in the function qma6100p_set_data_ready_int. In fact, the function _set_intpin_conf won't set the value of map_reg in the default case.

It is possible that the compiler can't resolve the goto conditions properly and therefore assumes that map_reg might be used uninitialized.

In general, I think the use of goto and the READ_REG macros that also get the goto label as a parameter is not really a good style tbh.

AnnsAnns · 2026-06-07T18:49:23Z

It is possible that the compiler can't resolve the goto conditions properly

The compiler once it sees goto

baptleduc · 2026-06-07T19:24:11Z

In general, I think the use of goto and the READ_REG macros that also get the goto label as a parameter is not really a good style tbh.

You are right, but where do you see such usage ? You mean that we shouldn't pass the goto label as parameter of READ_REG macros ? So it will make the READ_REG/WRITE_REG macro useless

benpicco · 2026-06-08T13:02:44Z

+    (void)args;
+    irq_count++;
+    if (reader_pid != KERNEL_PID_UNDEF) {
+        thread_flags_set(thread_get(reader_pid), FLAG_DATA_READY);


Why not just use a mutex?

benpicco · 2026-06-08T13:06:00Z

+ * @param[in]  dev          device descriptor of accelerometer
+ * @param[out] data         raw ADC counts per axis
+ *
+ * @return                  QMA6100P_NODATA if nothing has changed and keep data unchanged.


QMA6100P_NODATA is not defined

benpicco · 2026-06-08T13:11:09Z

+    if (res == -ENXIO) {
+        return QMA6100P_NODEV;
+    }
+    if (res == -EINVAL) {
+        return QMA6100P_INVALID_ARG;


Why use custom error codes here?

It is a wrapper as one of the maintainer suggest when I did the ads1x1x driver

benpicco · 2026-06-08T13:11:49Z

+    /* Wait for OTP to load */
+    do {
+        READ_REG(QMA6100P_REG_NVM, nvm_status, out);
+    } while ((nvm_status & (QMA6100P_NVM_LOAD_DONE | QMA6100P_NVM_RDY)) !=


better add a limit on the number of retries

benpicco · 2026-06-08T13:20:27Z

+ * @brief   Interrupt configuration parameters
+ */
+typedef struct {
+    gpio_t interrupt_pin;                         /**< MCU GPIO connected to the QMA6100P INT pin */


This should be part of qma6100p_params_t

benpicco · 2026-06-08T13:20:49Z

+typedef struct {
+    gpio_t interrupt_pin;                         /**< MCU GPIO connected to the QMA6100P INT pin */
+    qma6100p_int_active_level_t active_level_int; /**< active level of INT pin */
+    qma6100p_int_pin_mode_t pin_mode_int;         /**< INT pin output mode */


Why would you need this to be configurable?

benpicco · 2026-06-08T13:21:00Z

+    gpio_t interrupt_pin;                         /**< MCU GPIO connected to the QMA6100P INT pin */
+    qma6100p_int_active_level_t active_level_int; /**< active level of INT pin */
+    qma6100p_int_pin_mode_t pin_mode_int;         /**< INT pin output mode */
+    qma6100p_int_shadow_t interrupt_shadow;       /**< shadow mode */


What does this mean?

benpicco · 2026-06-08T13:21:41Z

+    qma6100p_int_active_level_t active_level_int; /**< active level of INT pin */
+    qma6100p_int_pin_mode_t pin_mode_int;         /**< INT pin output mode */
+    qma6100p_int_shadow_t interrupt_shadow;       /**< shadow mode */
+    qma6100p_int_pin_num_t interrupt_pin_num;     /**< QMA6100P INT pin routed on the board */


I guess that means you can have multiple interrupt pins for different events?

benpicco · 2026-06-08T13:26:05Z

+ *
+ * Work mode is controlled by PM_REGISTER (0x11) and can be set through I2C commands
+ *
+ * @warning By default, QMA6100P is in intermediate state after power on but it shouldn't be keep for any applications


Then there should only be a qma6100p_set_low_power(bool) right?

benpicco · 2026-06-08T13:29:15Z

+ *
+ * @warning The callback is invoked from interrupt context, keep it short
+ */
+int qma6100p_set_data_ready_int(qma6100p_t *dev, const qma6100p_int_t *interrupt);


I guess the more idiomatic way would be

Suggested change

int qma6100p_set_data_ready_int(qma6100p_t *dev, const qma6100p_int_t *interrupt);

int qma6100p_set_data_ready_int(qma6100p_t *dev, const qma6100p_int_params_t *config, qma6100p_int_cb_t cb, void *arg);

benpicco · 2026-06-08T13:30:09Z

+ */
+typedef enum {
+    QMA6100P_INT_CFG_SHADOW_EN = 0,  /**< shadowing enabled (default) */
+    QMA6100P_INT_CFG_SHADOW_DIS = 1, /**< shadowing disabled */


What does that even mean?
